Serial number |
describe |
parameter |
|
one |
XTheYTheZAxial travel |
1300*1800*100mm |
|
two |
Platform rulerinch |
1450*1950mm |
|
three |
Maximum operating speed |
12m/min |
|
four |
Maximum carving speed |
6-8m/min |
|
five |
resolving power |
0.01mm |
|
six |
Repetitive positioning accuracy |
< 0.05mm |
|
seven |
processor |
Weihong |
|
eight |
Carving instructions |
Gcode*.u00*.mmg*.plt |
|
nine |
Software operating environment |
win98/2000/xp |
|
ten |
working voltage |
AC220V/50Hz |
|
eleven |
Spindle power |
1.5KW |
|
twelve |
Spindle speed |
0--24000r/min |
|
thirteen |
operation mode |
SteppingStepper |
◆Six machine heads can process at the same time, which is six times more efficient than a single engraving machine.◆SW1318Six heads areScrew drive,Economical and cost-effective.
◆Made in Germany, high-precision pre tightened anti backlash ball screws minimize the clearance generated during motion. Make the positioning accuracy more accurate.
◆Taiwan Shangyin linear guide rail, self-lubricating slider, with equal force in all directions during carving,Ensuring mechanical accuracy and strength.
◆During batch processing, the product has good consistency and high quality.
◆The overall cast iron bed is sturdy and does not deform. Longmen style mobile,The workbench is fixed and can process materials on the workbench freely.
◆Adopting the Weihong CNC system, it can achieve breakpoint continuation carving and power-off memory function, with convenient and intuitive operation, suitable for relief carving.◆CompatibleType3/Artcam/Fine carving/Various types such as WentaiCAD/CAMGenerated by design softwareGProcessing code.
Specially designed for customers who require large-scale and small workpiece processing, suitable for processing cabinet doors, craft gifts, relief crafts, non-ferrous metal carving and cutting, and many other industry products.
